Description
Maintenance switch, 3-p. 415V AC23 100A, 55kW. Mounted auxiliary contact: 0NO0NC. Aluminium enclosure. IP65. Black. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Conventional Thermal Current | Fully Enclosed 100 A |
|---|---|
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Max Mounted Aux Contacts | 1 NO, 1 NC |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Pollution Degree | 3 |
| Enclosure Material | Aluminium |
| Enclosure Type | Frontex2 |
| Handle Color | Black |
| Handle Type | Round |
| Impact Resistance Rating | Housing IK09 |
| Mechanical Durability | 200000 |
| Neutral Type | Fixed Neutral |
| Product Net Width | 160 mm |
| Product Net Height | 230 mm |
| Product Net Depth / Length | 118 mm |
| Product Net Weight | 2.09 kg |
| Package L1 Width | 150 mm |
| Package L1 Height | 240 mm |
| Package L1 Gross Weight | 2.27 kg |
| EAN | 6417019936185 |
| Cable Entry Position | Top/Bottom |
| Cable Outlets Per Side | 2xM40 / 2xM40+M16 |
| Connecting Capacity Main Circuit | Screw Clamp 2.5…70 mm²; PE 1pc 6…35 mm² |
| Customs Tariff Number | 85365080 |
| Data Sheet Docs | 1SCC340017C0201; 1SCC340015C0201 |
| Package L1 Units | box 1 piece |
| Package L1 Length | 170 mm |
| Package L1 EAN | 6417019936185 |
| Manufacturer standard delivery time | 14 days |
| Packaging unit | Box x 1 |
| Product status (supplier data) | New product |
Independent distributor — not an authorised ABB dealer. All technical parameters are taken verbatim from the official ABB product data for this exact order code; packaging, customs and delivery data come from the supplier list entry for the same code.
