Description
C.breaker tmax xt1s 125 ul/csa fixed four-pole with front terminals and thermomagnetic release tmf r 100-1000 a. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Current Type | AC/DC |
|---|---|
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Suitable for Product Class | SACE Tmax XT |
| Version | F |
| Electrical Durability (1 of 2) | 120 cycles per hour |
| Electrical Durability (2 of 2) | 8000 cycle |
| Mechanical Durability (1 of 2) | 240 cycles per hour |
| Mechanical Durability (2 of 2) | 25000 cycle |
| Name | XT1S 125 TMF 100-1000 4p F F UL/CSA |
| Product Net Width | 101.6 mm |
| Product Net Height | 130 mm |
| Product Net Depth / Length | 70 mm |
| Product Net Weight | 1.4 kg |
| Width | 101.6 mm |
| Height | 130 mm |
| Depth | 70 mm |
| Weight | 1.4 kg |
| EAN | 8015644786687 |
| Customs Tariff Number | 85362090 |
| Connecting Capacity Main Circuit | Busbar 45.5 … 80 mm² |
| Category | Tmax XT |
| Description | C.BREAKER TMAX XT1S 125 UL/CSA FIXED FOUR-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMF R 100-1000 A |
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Extended Product Lifetime | Product is Modular |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops – Standard EN45555 – 55.9 % |
| Country of origin | Italy |
| Manufacturer standard delivery time | 8 days |
| Packaging unit | Box x 1 |
| Product status (supplier data) | Active |
Independent distributor — not an authorised ABB dealer. All technical parameters are taken verbatim from the official ABB product data for this exact order code; packaging, customs and delivery data come from the supplier list entry for the same code.
