Description
The CR-P048AC2 pluggable interface relay is suitable for direct mounting on a printed circuit board or use … in conjunction with ABB’s sockets. This relay operates with a 48 V AC rated control supply voltage … and has a 2 c/o (SPDT) output with contacts rated at 250 V / 8 A … IP degree of 67, this relay offers complete protection against ingress of dust … Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Function | Pluggable pcb interface relay CR-P |
|---|---|
| Sub-Function | Relay w/o built in LED |
| Rated Control Supply Voltage (Us) | 48 V AC |
| Rated Operational Voltage | 400 V AC |
| Output | 2 C/O Contacts; 2 C/O Contacts (enumerationValueCode: 2COContacts) |
| Output Signal | 250 V / 8 A |
| Rated Operational Current AC-12 | (230 V) 8 A |
| Rated Operational Current AC-15 | (120 V) 3 A; (230 V) 1.5 A |
| Rated Operational Current DC-12 | (24 V) 8 A |
| Rated Operational Current DC-13 | (24 V) 2 A; (250 V) 0.1 A |
| Rated Insulation Voltage (Ui) | 400 V |
| Degree of Protection | IP67 |
| Maximum Operating Voltage UL/CSA | 300 V AC |
| Terminal Type | Soldering Pins |
| Mounting Position | 1 |
| Standards | IEC/EN 61810-1 |
| Ambient Air Temperature | Operation -40 … +70 °C; Storage -40 … +85 °C |
| Maximum Operating Altitude Permissible | Without Derating 2000 m |
| Product Net Width | 12.7 mm |
| Product Net Height | 15.7 mm |
| Product Net Depth / Length | 29 mm |
| Product Net Weight | 0.014 kg |
| EAN | 4013614498275 |
| Customs Tariff Number | 85364900 |
| Pilot Duty UL/CSA | B300 |
| Flammability According to UL94 | V-0 |
| Category | Interface Relays and Optocouplers |
| Country of origin | Poland |
| Manufacturer standard delivery time | 5 days |
| Packaging unit | Box x 10 |
| Product status (supplier data) | Active |
