Description
Pluggable miniature interface relay for an ABB CR-M socket; DIN-rail mountable with the socket; 12 V DC control; 4 c/o (SPDT), 250 V / 6 A output; test button and LED; accessories include sockets, function modules, holders and markers. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Function | Pluggable miniature interface relay CR-M |
|---|---|
| Sub-Function | Relay with built in LED |
| Rated Control Supply Voltage (Us) | 12 V DC |
| Rated Operational Voltage | 250 V AC |
| Output | 4 C/O (SPDT) Contacts |
| Output Signal | 250 V / 6 A |
| Rated Operational Current AC-12 (Ie) | (230 V) 6 A |
| Rated Operational Current AC-15 (Ie) | (120 V) 1.5 A; (230 V) 1 A |
| Terminal Type | Flat-Pin Connections |
| Product Net Width | 21.2 mm |
| Product Net Height | 35.6 mm |
| Product Net Depth / Length | 27.5 mm |
| Product Net Weight | 0.033 kg |
| EAN | 4013614497780 |
| Customs Tariff Number | 85364900 |
| Manufacturer standard delivery time | 5 days |
| Packaging unit | Box x 10 |
| Product status (supplier data) | Active |
Independent distributor — not an authorised ABB dealer. All technical parameters are taken verbatim from the official ABB product data for this exact order code; packaging, customs and delivery data come from the supplier list entry for the same code.
