Description
The CR-U024DC3L pluggable interface relay is a univeral relay and is also commonly referred to as an ice cube relay. This relay operates with a 24 V DC rated control supply voltage and has a 3 c/o (SPDT) output. The relay has an integrated test button and integrated LED, which provides the visual indication. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Control voltage | 24 V DC |
|---|---|
| Output contacts | 3 c/o (SPDT), rated 250 V / 10 A |
| Terminals | robust circular pin terminals |
| Mounting | DIN Rail via CR-U sockets |
| Width | 35 mm |
| Height | 54.4 mm |
| Depth | 35 mm |
| Weight | 0.083 kg |
| EAN | 4013614498589 |
| Led | integrated (coil energization indication) |
| Test button | integrated (manual actuation / locking) |
| Customs tariff number | 85364900 |
| Manufacturer standard delivery time | 5 days |
| Packaging unit | Box x 10 |
| Product status (supplier data) | Active |
Independent distributor — not an authorised ABB dealer. All technical parameters are taken verbatim from the official ABB product data for this exact order code; packaging, customs and delivery data come from the supplier list entry for the same code.
