Description
The CP-E 24/0.75 is a power supply from the CP-E range. The primary switch mode power supply offers a wide range input of 90-264 V AC and 120-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 18 W, rated output current is 0.75 A at an output voltage of 24 V DC. The output voltage is adjustable within a range of 21.6 to 28.8 V DC. The output characteristic is hiccup-mode. The power supply allows parallel operation to enable redundancy. A redundancy unit is available as accessory. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Output Voltage | 24 V DC (adjustable 21.6 … 28.8 V DC) |
|---|---|
| Output Current | 0.75 A |
| Output Power | 18 W |
| Input Voltage Range | 90 … 264 V AC / 120 … 375 V DC |
| Rated Input Voltage | 100 … 240 V AC |
| Output Characteristic | hiccup-mode |
| Product Width | 22.5 mm |
| Product Depth | 114 mm |
| Product Height | 90 mm |
| Net Weight | 0.143 kg |
| Width | 22.5 mm |
| Depth | 114 mm |
| Height | 90 mm |
| Weight | 0.143 kg |
| Parallel Operation | allowed, to enable redundancy |
| EAN | 4016779656863 |
| Customs tariff number | 85044095 |
| Manufacturer standard delivery time | 5 days |
| Packaging unit | Box x 1 |
| Product status (supplier data) | Active |
Independent distributor — not an authorised ABB dealer. All technical parameters are taken verbatim from the official ABB product data for this exact order code; packaging, customs and delivery data come from the supplier list entry for the same code.
