Description
Block AVB 0,5/2/12. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Block |
|---|---|
| Article No. (MPN) | AVB 0,5/2/12 |
| Product Category | Transformers & Reactors |
| Series | AVB |
| Power | 0.5 VA |
| Input | 2 x 115 V |
| Output | 2 x 12 V • 0.021 Aac |
| Frequency range | 50 Hz to 60 Hz |
| Short-Circuit Losses | 0.65 W |
| No-Load Losses | 0.03 W |
| Short circuit voltage uk | 51 % |
| EN Insulation class | B (130°C) |
| UL Insulation class | class 105 |
| Duty Cycle | 100 % |
| Wire material | Copper |
| Efficiency | 42.4 % |
| Short circuit proof | inherently short-circuit proof |
| Switching group | IIii0 |
| Cooling type | AN |
| Ambient temperature | -20 °C to 70 °C / -4 °F to 158 °F |
| Max. installation height | 2,000 m / 6,562 ft |
| Protection type | IP00 |
| Protection class (prepared) | II |
| Overvoltage category | III |
| Condition | New & original |
| Availability | On request |
Download official Block datasheet (PDF)
Independent distributor — not an authorised Block dealer. All parameters are taken from the official manufacturer documentation.
