Description
Block DNC 24-15 C — Non-stabilized DC power supply. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Block |
|---|---|
| Article No. (MPN) | DNC 24-15 C |
| Product Category | Power Supplies |
| Series | DNC |
| Duty Cycle | 100 % |
| EN Insulation class | B (130°C) |
| Frequency range | 50 Hz to 60 Hz |
| Power | 360 VA |
| Wire material | Copper |
| UL Insulation class | class 130 |
| Short circuit proof | not short-circuit proof |
| Cooling type | AN |
| Switching group | IIId0 |
| Max. installation height | 2,000 m / 6,562 ft |
| Ambient temperature | -20 °C to 60 °C / -4 °F to 140 °F |
| Protection type | IP00 |
| Output terminal | Screw terminal |
| Input terminal | Screw terminal |
| Terminal PE | Screw terminal |
| Width | 165 mm / 6.5 in |
| Height | 190 mm / 7.48 in |
| Depth | 164 mm / 6.46 in |
| Weight | 6.221 kg / 13.715 lbs |
| Low Voltage Directive | EN 61558-2-6 |
| Condition | New & original |
| Availability | On request |
Download official Block datasheet (PDF)
Independent distributor — not an authorised Block dealer. All parameters are taken from the official manufacturer documentation.
