Description
Block EB-1748-060-0 — 1-Channel circuit breaker thermomagnet. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Block |
|---|---|
| Article No. (MPN) | EB-1748-060-0 |
| Product Category | Circuit Breakers |
| Series | EB-48 |
| Rated input voltage | 48 Vdc |
| Input voltage range | 32 Vdc to 58 Vdc |
| Max. continuous current of the module | 6 A |
| Max. continuous current feed terminal (+) | 40 A |
| Switch-on threshold | 31.40 V |
| Rated output voltage | 48 Vdc |
| Rated Output Current | 6 A |
| Rated Output Current per Output Channel | 6 A |
| Switch-off threshold | 31 V |
| Max. feedback resistance | 58 Vdc |
| Power losses in stand-by mode | 0.30 W |
| Parallel connection of outputs | Not permitted |
| Series connection of outputs | Not permitted |
| Release Characteristics | Thermomagnetic characteristic |
| Status display | Green, yellow, red LED |
| Storage temperature | -25 °C to 85 °C / -13 °F to 185 °F |
| Humidity without condensation | 5 % to 96 % |
| Required minimum distance (side) | 0 mm |
| Required minimum distance (top/bottom) | 30 mm |
| Width | 12 mm / 0.47 in |
| Condition | New & original |
| Availability | On request |
Independent distributor — not an authorised Block dealer. All parameters are taken from the official manufacturer documentation.
