Description
Block EB-1824-020-0 — 1-Channel circuit breaker current-limi. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Block |
|---|---|
| Article No. (MPN) | EB-1824-020-0 |
| Product Category | Circuit Breakers |
| Series | EB-18 |
| Rated input voltage | 24 Vdc |
| Input voltage range | 18 Vdc to 30 Vdc |
| Max. continuous current of the module | 2 A |
| Max. continuous current feed terminal (+) | 40 A |
| Max. ripple of the feeding input voltage | 3 % |
| Switch-on threshold | 17.50 V |
| Rated output voltage | 24 Vdc |
| Rated Output Current | 2 A |
| Rated Output Current per Output Channel | 2 A |
| Output voltage range | 24 Vdc |
| Switch-off threshold | 16.7 V |
| Max. voltage drop between input and output | 55 mV |
| Idle current @ 24 V | 39 mA |
| Max. feedback resistance | 35 Vdc |
| Power losses in stand-by mode | 1.20 W |
| Parallel connection of outputs | Not permitted |
| Series connection of outputs | Not permitted |
| Release Characteristics | Active current limiting |
| Status display | Green, yellow, red LED |
| Climate class according to EN 60721 | 3K3 |
| Condition | New & original |
| Availability | On request |
