Description
Block HLE 110-230/30 — Radio interference suppression filter. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Block |
|---|---|
| Article No. (MPN) | HLE 110-230/30 |
| Product Category | Transformers & Reactors |
| Series | HLE 110 |
| Inductance | 2.97 mH |
| Rated current | 30 Aac |
| Rated voltage range | 0 V to 250 V |
| Rated voltage | 230 V |
| Frequency range | 50 Hz to 60 Hz |
| Motor or converter power | 2.2 kW / 2.95 HP |
| EN Insulation class | A (105°C) |
| UL Insulation class | class 105 |
| Duty Cycle | 100 % |
| Power loss | 8.50 W |
| Wire material | Copper |
| Cooling type | AN |
| Ambient temperature | -25 °C to 50 °C / -13 °F to 122 °F |
| Protection type | IP20 |
| Input terminal | Screw terminal |
| Output terminal | Screw terminal |
| Terminal PE | Bolt connection |
| Width | 50 mm / 1.97 in |
| Height | 95 mm / 3.74 in |
| Depth | 230 mm / 9.06 in |
| Condition | New & original |
| Availability | On request |
Download official Block datasheet (PDF)
Independent distributor — not an authorised Block dealer. All parameters are taken from the official manufacturer documentation.
