Description
Crydom GN — SSR Relay. Manufacturer designation: 90-280 vac 100 a. SSR Relay, Panel Mount, IP00, 280VAC/100A, AC In, Zero Cross New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Crydom |
|---|---|
| Model / Type | GN |
| Article No. (MPN) | 84134041 |
| Product Category | Relays & Couplers |
| Maximum Load Current [Arms] (3) | 100 |
| Minimum Load Current [mArms] | 100 |
| Maximum 1 Cycle Surge Current (50/60 Hz) [Apk] | 1120/1200 |
| 1 Second surge current (Apk. Ta=25°C) 50/60 Hz | 300 |
| Maximum On-State Voltage Drop @ Rated Current [Vpk] | 1.3 |
| Thermal Resistance Junction to Case (Rjc) [°C/W] | 0.16 |
| Maximum 1/2 Cycle I² t for Fusing (50/60Hz) [A² sec] | 6270/6000 |
| Minimum Heat Sink for Rated Current @ 40°C [°C/W] | 0.5 |
| Dielectric Strength, Input/Output/Base (50/60 Hz) | 4000 Vrms |
| Minimum Insulation Resistance (@ 500 VDC) | 10^9 Ohms |
| Maximum Capacitance, Input/Output | 8 pF |
| Ambient Operating Temperature Range (7) | -40 to 80 °C |
| Ambient Storage Temperature Range | -40 to 125 °C |
| Weight (typical) | 2.53 oz (72 g) |
| Housing Material UL94 V | -0 |
| Condition | New & original |
| Availability | On request |
Download official Crydom datasheet (PDF)
Independent distributor — not an authorised Crydom dealer. All parameters are taken from the official manufacturer documentation.
