Description
Dehn VK 6.22 FL40 KB6.10 BSB STBL — Connection Clamp For Round Conductor. Manufacturer designation: For T, cross and parallel connections with clamping piece. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Dehn |
|---|---|
| Model / Type | VK 6.22 FL40 KB6.10 BSB STBL |
| Article No. (MPN) | 308035 |
| Product Category | Earthing & Lightning Protection |
| Material | St/bare |
| Clamping range Rd / Rd | (+/II) 6-22 / 6-10 mm |
| Clamping range Rd / Fl | (+) 6-22 / 40 mm |
| Screw | d i M10 x 60 mm |
| Standard | EN 62561-1 |
| Short-circuit current (AC 50 Hz / DC) (1 s; ≤ 300 °C) | 1.0 kA |
| EAN / GTIN | 4013364123472 |
| Condition | New & original |
| Availability | On request |
Independent distributor — not an authorised Dehn dealer. All parameters are taken from the official manufacturer documentation.
