Description
Gewiss GW62280 — 10° ANGLED FLUSH-MOUNTING. Manufacturer designation: 10° angled flush-mounting socket-outlet – IP44 – 2P 32A 20-25V and 40-. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Gewiss |
|---|---|
| Article No. (MPN) | GW62280 |
| Product Category | Distribution & Installation |
| Colour | Green |
| Rated current (A) | 32 |
| IP degree | IP44 |
| No. of poles | 2P |
| Mechanical resistance | IK08 |
| Reference h | 11 |
| Flange dimensions (mm) | 85×75 |
| Type | 10° angled flush-mounting socket-outlet |
| Rated voltage | 20-25 V and 40-50 V |
| Frequency | 401 – 500 Hz |
| Terminal tightening capacity | 2.5-6 mm² flexible cables – 2.5-10 mm² rigid cables |
| Operating temperature | -25 +40 °C |
| Type of wiring | With screw |
| Electrocod | 2210 |
| Glow wire test | 850 °C (active parts) – 650 °C (passive parts) |
| Total number of operations | > 2000 |
| Permissible overload | 42 A |
| Breaking capacity at 1.1 Un | 40 A |
| Insulation resistance | > 10 MΩ |
| Thermo-pressure with ball | 125 °C (active parts) – 80 °C (passive parts) |
| Ware Number | 85366990 |
| Condition | New & original |
| Availability | On request |
