Description
Legrand 028132 — Shunt Release. Manufacturer designation: Shunt release for DMX³1600 – 48V~ or 48V=. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Legrand |
|---|---|
| Article No. (MPN) | 028132 |
| Product Category | Distribution & Installation |
| Nominal AC supply voltage 50 Hz (Min-Max) | 43.2-52.8V |
| Nominal AC supply voltage 60 Hz (Min-Max) | 43.2-52.8V |
| Nominal DC supply voltage (Min-Max) | 43.2-52.8V |
| Actuation voltage type | AC/DC |
| Electrical connection finishing | Flat pin connection |
| Suitable for circuit breaker | Yes |
| Suitable for switch | Yes |
| Suitable for motor protection switch | Yes |
| Adapté à un relais de surcharge | Yes |
| Operating / setting temperature (Min-Max) | -25-70°C |
| Storage temperature (Min-Max) | -25-70°C |
| Fréquence (Min-Max) | 0-60Hz |
| Indication de repérage des bornes de raccordement | Yes |
| Terminal capacity (Min-Max) | 0.5-1.5mm² |
| Ean/gtin | 3414970767011 |
| EAN / GTIN | 3414970767011 |
| Condition | New & original |
| Availability | On request |
Independent distributor — not an authorised Legrand dealer. All parameters are taken from the official manufacturer documentation.
