Description
Phoenix Contact 0205290 — PSB 6/5/6. Manufacturer designation: PSB 6/5/6 – Test plug strip – 0205290. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Phoenix Contact |
|---|---|
| Article No. (MPN) | 0205290 |
| Product Category | Terminals & Connectors |
| Product type | Test socket |
| Connection method | Plug-in connection |
| Dimensional drawing Width | 6 mm |
| Height | 6 mm |
| Pin diameter | 4.1 mm |
| Color | silver-colored |
| Contact material | Silver-plated brass |
| Ambient temperature (operation) | -40 °C … 80 °C |
| Item number | 0205290 |
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Sales key | BE19 |
| Product key | BE1Z3X |
| Gtin | 4017918098964 |
| Weight per piece (including packing) | 2.8 g |
| Weight per piece (excluding packing) | 2.48 g |
| Customs tariff number | 85366990 |
| Country of origin | PL |
| Eclass-13.0 | 27250304 |
| Eclass-15.0 | 27250304 |
| Etim 10.0 | EC002555 |
| Condition | New & original |
| Availability | On request |
Independent distributor — not an authorised Phoenix Contact dealer. All parameters are taken from the official manufacturer documentation.
