Description
Phoenix Contact 0710866 — EBL 3- 5. Manufacturer designation: EBL 3- 5 OG – Insertion bridge – 0710866. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Phoenix Contact |
|---|---|
| Article No. (MPN) | 0710866 |
| Product Category | Terminals & Connectors |
| Product type | Insertion bridge |
| Pitch | 5.2 mm |
| Color | orange (RAL 2003) |
| Ambient temperature (operation) | -60 °C … 105 °C |
| Ambient temperature (assembly) | -5 °C … 70 °C |
| Ambient temperature (actuation) | -5 °C … 70 °C |
| Permissible humidity (storage/transport) | 30 % … 70 % |
| Item number | 0710866 |
| Packing unit | 100 pc |
| Minimum order quantity | 100 pc |
| Product key | BE1Z2X |
| Gtin | 4017918479329 |
| Weight per piece (including packing) | 1.1 g |
| Weight per piece (excluding packing) | 1.1 g |
| Country of origin | PL |
| Eclass-13.0 | 27250303 |
| Eclass-15.0 | 27250303 |
| Etim 10.0 | EC000489 |
| Unspsc 21.0 | 39121400 |
| EU RoHS Fulfills EU RoHS substance requirements | Yes |
| Condition | New & original |
| Availability | On request |
Independent distributor — not an authorised Phoenix Contact dealer. All parameters are taken from the official manufacturer documentation.
