Description
Rechner KAS-70-30EM/15-S-D30-PA-Z05-ETM-HP — Capacitive Sensors. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Rechner |
|---|---|
| Model / Type | KAS-70-30EM/15-S-D30-PA-Z05-ETM-HP |
| Article No. (MPN) | KA1468 |
| Product Category | Sensors |
| Operating distance Sn | 5 mm |
| Operating voltage (UB) | 10…35 V DC |
| Operating current (Ie) | 0…200 mA |
| Output function | Yellow |
| Electrical version | 3 wire DC |
| Housing | Ø 30 mm |
| Housing material | Polyamid |
| Degree of protection | IP68 |
| Ambient temperature | -25…+70°C |
| Connection | cable 5 m PVC, 3 x 0.14 mm² |
| Mounting | Flush |
| Condition | New & original |
| Availability | On request |
Download official Rechner datasheet (PDF)
Independent distributor — not an authorised Rechner dealer. All parameters are taken from the official manufacturer documentation.
