Description
Rechner KAS-80-39/23-A-D50-PTFE-Z05-MaG-Leak-3G, ATEX — Capacitive Sensors. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Rechner |
|---|---|
| Model / Type | KAS-80-39/23-A-D50-PTFE-Z05-MaG-Leak-3G, ATEX |
| Article No. (MPN) | KA1672 |
| Product Category | Sensors |
| Operating voltage (UB) | 10…35 V DC |
| Operating current (Ie) | 0…250 mA |
| Output function | Antivalent |
| Electrical version | 4-wire DC |
| Housing | Ø 50 mm |
| Housing material | PTFE |
| Degree of protection | IP 67 |
| Ambient temperature | 0…+60 °C |
| Connection | cable 5 m, FEP, screened, 4 x 0.14 mm |
| Mounting | Flush |
| Condition | New & original |
| Availability | On request |
Download official Rechner datasheet (PDF)
Independent distributor — not an authorised Rechner dealer. All parameters are taken from the official manufacturer documentation.
