Description
Schneider Electric BRS366H030AAA — Stepper Motor. Manufacturer designation: 3-phase stepper motor – 1.02 Nm – shaft Ø6.35 mm – L=56 mm – without brake -wire. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | BRS366H030AAA |
| Product Category | Drives & Controls |
| Range compatibility | Lexium SD3 |
| Product or component type | Motion control motor |
| Maximum mechanical speed | 3000 rpm |
| Motor type | 3-phase stepper motor |
| Number of motor poles | 6 |
| Supply voltage limits | 34 V DC; 48 V DC |
| Mounting support | Flange |
| Motor flange size | 57.2 mm |
| Length | 56 mm |
| Centring collar diameter | 38 mm |
| Centring collar depth | 1.6 mm |
| Number of mounting holes | 4 |
| Mounting holes diameter | 5.2 mm |
| Circle diameter of the mounting holes | 66.6 mm |
| Electrical connection | Flying leads |
| Holding brake | Without |
| Shaft end | Smooth shaft |
| Second shaft | Without second shaft end |
| Shaft diameter | 6.35 mm |
| Shaft length | 21 mm |
| Nominal torque | 0.9 N.m |
| EAN / GTIN | 3606485149349 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
