Description
Schneider Electric BRS39BW461FCA — Stepper Motor. Manufacturer designation: 3-phase stepper motor – 6.78 Nm – shaft Ø 14 mm – L=128 mm – with brake – conn. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | BRS39BW461FCA |
| Product Category | Drives & Controls |
| 127.5 (+0.6) (-0.8) | 14 h6; 60 h8; 5 x 6.5 |
| 5.02 (+0.023) (-0.031) | 0.55 h6; 2.36 h8; 0.20 x 0.25 |
| Pin | Designation |
| Range compatibility | Lexium SD3 |
| Product or component type | Motion control motor |
| Maximum mechanical speed | 3000 rpm |
| Motor type | 3-phase stepper motor |
| Number of motor poles | 6 |
| Supply voltage limits | 230 V AC; 325 V DC |
| Mounting support | Flange |
| Motor flange size | 85 mm |
| Length | 171 mm |
| Centring collar diameter | 60 mm |
| Centring collar depth | 2 mm |
| Number of mounting holes | 4 |
| Mounting holes diameter | 6.5 mm |
| Circle diameter of the mounting holes | 98.99 mm |
| Electrical connection | Connector |
| Feedback type | Single turn encoder |
| Speed feedback resolution | 10000 points/turn |
| Holding brake | With |
| EAN / GTIN | 3389119224123 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
