Description
Schneider Electric NSYAECPFLT7 — Cable Entry Membrane. Manufacturer designation: “Cable entry membrane, PanelSeT, PanelSet, type FL21 with 7 entrances IP66”. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYAECPFLT7 |
| Product Category | Enclosures & Junction Boxes |
| Range | PanelSeT |
| Product or component type | Cable entry membrane |
| Accessory / separate part category | Cable management accessory |
| Device application | Multi-purpose |
| Range compatibility | PanelSeT S3D compact enclosure; PanelSeT CRN compact enclosure; PanelSeT SF SF suitable enclosure |
| Device composition | 1 membrane; 1 fixing elements |
| Quantity per set | Set of 1 |
| Mounting support | Cable gland plate |
| Material | TPE (thermoplastic elastomer) |
| Fixing mode | By fixing element |
| Total cable entry number | 7 |
| Cable entry number | 2 x 24…54 mm; 1 x 30…60 mm; 4 x 10…14 mm |
| Height | 40 mm |
| Width | External: 214 mm; Fixing center: 194 mm |
| Depth | Fixing center : 62 mm; External : 88 mm |
| Colour | Grey (RAL 7035) |
| Net weight | 0.29 kg |
| IP degree of protection | IP66 |
| Flame retardance | V0 conforming to UL 94 |
| Ambient air temperature for operation | -40…100 °C |
| Environmental characteristic | Oil resistant conforming to UL 157 FIMKO; UV resistant; Weatherproof; Fire resistance conforming to UL 94 V0 |
| EAN / GTIN | 3606480169038 |
| Condition | New & original |
| Availability | On request |
