Description
Schneider Electric NSYCRN108300P — Servo Motor. Manufacturer designation: PanelSeT CRN plain door with mount.plate. H1000xW800xD300 IP66 IK10 RAL7035… New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYCRN108300P |
| Product Category | Enclosures & Junction Boxes |
| Range | PanelSeT |
| Product name | PanelSeT CRN |
| Application | Multi-purpose |
| Enclosure nominal height | 39.4 in (1000 mm) |
| Enclosure nominal width | 31.5 in (800 mm) |
| Enclosure nominal depth | 11.8 in (300 mm) |
| Installation accessory type | Wall-mounting |
| Device composition | 1 body; 1 door with lock; 1 mounting plate; 2 cable gland plate bottom |
| Door type | Solid |
| Mounting plate description | Plain |
| Body type | Back welded with double profile forming a protected sealed area; Sides made from a single folded section |
| Number of doors | Front face 1 |
| Door opening side | Reversible 120 °) |
| Lock type | 3 mm double-bar lock |
| Type of gland plate | Standard |
| Accessibility for operation | Front |
| Removable parts | Door by hinges; Cable gland plate by screws; Mounting plate by fixing element |
| Material | Enclosure steel; Mounting plate galvanised steel |
| Surface finish | Enclosure epoxy-polyester powder |
| Color | Enclosure Gray RAL 7035) |
| Standards | IEC 62208; UL; CUL |
| EAN / GTIN | 3606480212673 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
