Description
Schneider Electric NSYCRN86400T — Servo Motor. Manufacturer designation: Glazed steel door, PanelSeT CRN, without mounting plate, 800x600x400mm, IP66, IK08, RAL7035. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYCRN86400T |
| Product Category | Enclosures & Junction Boxes |
| Range | PanelSeT |
| Product name | PanelSeT CRN |
| Application | Multi-purpose |
| Enclosure nominal height | 31.5 in (800 mm) |
| Enclosure nominal width | 23.6 in (600 mm) |
| Enclosure nominal depth | 15.7 in (400 mm) |
| Installation accessory type | Wall-mounting |
| Device composition | 1 body; 1 cable gland plate; 1 door; 1 lock |
| Door type | Glass |
| Mounting plate description | Without mounting plate |
| Body type | Single piece body |
| Number of doors | Front face 1 |
| Door opening side | Reversible 120 °) |
| Lock type | 3 mm double-bar lock |
| Type of gland plate | Standard |
| Accessibility for operation | Front |
| Removable parts | Door by hinges; Cable gland plate by screws |
| Material | Body steel; Door steel and security glass |
| Surface finish | Epoxy-polyester powder |
| Color | Gray RAL 7035) |
| Standards | IEC 62208; UL; CUL |
| EAN / GTIN | 3606485891255 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
