Description
Schneider Electric NSYMD33 — Chassis. Manufacturer designation: Symmetrical mounting chassis (4 rails) for enclosure dimensions H300xW300mm. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYMD33 |
| Product Category | Enclosures & Junction Boxes |
| Anwendung | Multi-purpose |
| Range | PanelSeT |
| Product or component type | Chassis |
| Accessory / separate part category | Mounting accessory |
| Type of rail | Symmetrical DIN |
| Enclosure nominal dimensions | – H: 300 mm W: 300 mm D: 150 mm; – H: 300 mm W: 300 mm D: 200 mm |
| Mounting support | Direct fixing on backstuds; Spacer; Step slide |
| Range compatibility | PanelSeT CRN; PanelSeT S3D; PanelSeT PLM |
| Device composition | Fixing elements; 2 upright; 4 DIN rail |
| Quantity per set | Set of 1 |
| Material | Uprights: aluminium; Rail: galvanized steel |
| Fixing mode | Screwed on backstuds; By fixing element |
| Adjustment | On step slides, type NSYSDCR…, pitch 12.5 mm |
| Height | Nominal: 300 mm; Real: 239.3 mm |
| Width | Nominal: 300 mm; Real: 250 mm |
| Depth | Real : 30 mm |
| Unit Type of Package 2 | PAM |
| Number of Units in Package 2 | 300 |
| Package 2 Height | 45.000 cm |
| Package 2 Width | 100.000 cm |
| Package 2 Length | 120.000 cm |
| EAN / GTIN | 3606480182815 |
| Condition | New & original |
| Availability | On request |
