Description
Schneider Electric NSYOPB12U4FR — 19″ Enclosure. Manufacturer designation: Wall-Mounted Open Box 12U W600 D400 Fixed 19″ Plain Door R7035. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYOPB12U4FR |
| Product Category | Enclosures & Junction Boxes |
| Range | Actassi |
| Product name | Actassi OPB |
| Product or component type | 19″ enclosure |
| Device application | Cabling |
| Applications | To protect network connectivity equipment; To mount 19″ equipment; To improve security of the equipment |
| Enclosure type | Open box |
| Support equipment | 2 x fixed 19″ uprights recessed of 120 mm from the front (pitch 25 mm) |
| Front face | Plain door |
| Door type | Front plain door – with 1 point locking system (key: 333) – reversible opening at 180 ° |
| Accessibility for operation | Side; Front; Rear |
| Removable parts | Front door removable toolless; Top blanking plate; Bottom blanking plate; Rear blanking plate; Side panels removable toolless |
| Colour | Light grey (RAL 7035) |
| Device composition | 3 x cable entries; 2 x panels side; 2 x 19″ uprights front; 1 x open structure; 1 x plain door front |
| Load rating | 50 kg static; 3 kg by unit |
| Back face | Cut-out |
| Side face | Panel |
| Number of cut-out | 1 cut-outside; 1 cut-outbottom; 1 cut-outtop |
| Installation mode | Wall mounted |
| Material | Sheet steel: structure; Sheet steel: door; Galvanized steel: upright |
| Surface finish | Epoxy-polyester powder |
| Width | 600 mm |
| EAN / GTIN | 3606480287602 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
