Description
Schneider Electric NSYPFXPLM — Wall Fixing Support. Manufacturer designation: Set of 4 stainless steel wall mounting lugs for PLM3025 to 108. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYPFXPLM |
| Product Category | Enclosures & Junction Boxes |
| Range | PanelSeT |
| Accessory / separate part category | Fixing accessory |
| Product or component type | Wall fixing support |
| Device application | Multi-purpose |
| Enclosure nominal dimensions | – |
| Mounting location | Top and bottom, on rear of the enclosure |
| Range compatibility | PanelSeT PLM PLM |
| Device composition | Fixing screws; 4 lug |
| Material | Stainless steel |
| Fixing mode | Screwed – from the outside location |
| Permanent permissible load | 100 kg horizontal position; 200 kg vertical position |
| Height | 40 mm |
| Width | 155 mm |
| Depth | 80 mm |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 50 |
| Package 2 Height | 42.500 cm |
| Package 2 Width | 32.000 cm |
| Package 2 Length | 23.000 cm |
| Package 2 Weight | 19.200 kg |
| Unit Type of Package 3 | PAM |
| EAN / GTIN | 3606480191978 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
