Description
Schneider Electric NSYPHDT753P — Servo Motor. Manufacturer designation: Thalassa PHD outdoor heavy duty – enclosure H788 W500 D320 IP65 plain door. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Schneider Electric |
|---|---|
| Article No. (MPN) | NSYPHDT753P |
| Product Category | Enclosures & Junction Boxes |
| Range | PanelSeT |
| Product | PHD |
| Application | Outdoor heavy duty |
| Certification | UL conforming to UL 508 A 2007; Bureau Veritas conforming to IEC 61969-3 2011; Bureau Veritas conforming to IEC 61439-5 2010; DEKRA conforming to IEC 62208 2011 |
| Enclosure type | Multi-purpose |
| Version | PHDZT |
| Enclosure height with canopy | 788 mm |
| Canopy height | 38 mm |
| Enclosure width | 500 mm |
| Enclosure depth | 320 mm |
| Enclosure mounting | Wall mounted |
| Body type | Sealed assembled body |
| Door type | Plain |
| Number of doors | 1 door(s) |
| Door opening side | Right or left (120 °) |
| Lock type | 2 points lock, handle with 1242E key lock and padlock |
| Accessibility for operation | Front |
| Maximum static load | 180 kg |
| Removable parts | Door by hinges |
| Material | Polyester double reinforced with fibreglass |
| Colour | Grey (RAL 7035) |
| EAN / GTIN | 3606480675997 |
| Condition | New & original |
| Availability | On request |
Download official Schneider Electric datasheet (PDF)
Independent distributor — not an authorised Schneider Electric dealer. All parameters are taken from the official manufacturer documentation.
