Description
Telemecanique Sensors 9007FTSB1M11 — LIMIT SWITCH. Manufacturer designation: Limit switch, 9007, 9007FT foundry standard,. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | 9007FTSB1M11 |
| Product Category | Sensors |
| Range of product | 9007 |
| Series name | Severe duty foundry |
| Product or component | Limit switch |
| Device application | Standard foundry switch |
| Device short name | 9007T/FT |
| Body type | Fixed |
| Head type | Rotary head |
| Base plate style | Style B |
| Body material | Cast zinc |
| Fixing mode | By the body |
| Movement of operating head | Rotary |
| Type of operator | Spring return without operating lever |
| Switch actuation | From left or right |
| Type of approach | Lateral approach |
| Electrical connection | Screw-clamp terminals AWG 22…AWG 12 |
| Cable entry | 1 entry for M20 – 20 mm conforming to BS 4568 |
| Switch function | SPDT-DB |
| Contact form | Form Z |
| Contact operation | Snap action |
| Contacts material | Silver flashed copper |
| Positive opening | Without |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
