Description
Telemecanique Sensors XEP4E1FDA454 — Microswitch. Manufacturer designation: Microswitch, Limit switches XC Standard,. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | XEP4E1FDA454 |
| Product Category | Sensors |
| Range of product | OsiSense XC |
| Series name | Special format |
| Product or component | Microswitch |
| Device short name | XEP4 |
| Detector design | Subminiature, DIN 41635 B format, sealed |
| Head type | Plunger head |
| Lever material | Stainless steel |
| Movement of operating | Linear |
| Type of operator | Roller lever |
| Type of approach | Lateral approach |
| Electrical connection | Pre-cabled |
| Cable length | 0.5 m |
| Cable composition | 3 x 0.5 mm² |
| Contacts type and | 1 C/O standard |
| Contact operation | Snap action |
| Contacts material | AgCdO |
| Body material | Polyester |
| Maximum force for tripping | 0.83 N lever fixing position in A |
| 1.67 n | lever fixing position in B |
| Minimum release force | 0.27 N lever fixing position in A |
| 0.53 n | lever fixing position in B |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
