Description
Telemecanique Sensors XT230A2MDB — Capacitive proximity sensors XT. Manufacturer designation: Capacitive proximity sensors XT, cylindrical. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | XT230A2MDB |
| Product Category | Sensors |
| Range of product | Telemecanique Capacitive proximity sensors XT |
| Sensor type | Capacitive proximity sensor |
| Product specific | Animal feeding |
| Sensor name | XT2 |
| Sensor design | Cylindrical M30 |
| Body type | Fixed |
| Detector flush mounting | Non flush mountable |
| Enclosure material | Plastic |
| Type of output signal | Discrete |
| Wiring technique | 2-wire |
| [Sn] nominal sensing | 15 mm |
| Discrete output function | 1 NO or 1 NC programmable |
| Output circuit type | AC |
| Electrical connection | Screw clamp terminal |
| [Us] rated supply | 24…240 V AC 50…60 Hz |
| Maximum delay | 10 ms |
| IP degree of protection | IP65 conforming to IEC 60529 |
| ISO thread | M30 x 1.5 |
| Detection face | Frontal |
| [Sa] assured operating distance | 0…11 mm |
| Adjustment zone | 0…17 mm |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
