Description
Telemecanique Sensors XUAH0203S — Photoelectric sensors XU. Manufacturer designation: Photoelectric sensors XU, XUA, emitter, 12…24. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | XUAH0203S |
| Product Category | Sensors |
| Range of product | Telemecanique Photoelectric sensors XU |
| Series name | Application assembly |
| Electronic sensor type | Photo-electric sensor transmitter |
| Sensor name | XUA |
| Sensor design | Cylindrical M8 |
| Detection system | Thru beam |
| Line of sight type | Axial |
| Supply circuit type | DC |
| Wiring technique | 3-wire |
| Electrical connection | 1 male connector M8, 3 pins |
| [Sn] nominal sensing | 2 m thru beam need a receiver |
| Enclosure material | Nickel plated brass |
| Lens material | PMMA |
| Add on input | Test by emission breaking |
| [Us] rated supply voltage | 12…24 V DC with reverse polarity protection |
| Supply voltage limits | 10…30 V DC |
| Current consumption | <= 15 mA |
| Maximum delay first up | 20 ms |
| Net weight | 0.015 kg |
| Product certifications | CE[RETURN]cULus |
| Ambient air temperature for operation | -25…55 °C |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
