Description
Telemecanique Sensors XUFZ910 — Photoelectric sensors XU. Manufacturer designation: Photoelectric sensors XU, plastic fibre optic for. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | XUFZ910 |
| Product Category | Sensors |
| Range of product | Telemecanique Photoelectric sensors XU |
| Sensor name | XUF |
| [Sn] nominal sensing | 0.075 M XUFZ03 axial |
| 0.075 m | XUFZ05 lateral |
| End fitting type | , without end fitting |
| Electronic sensor type | Photo-electric sensor |
| Sensor design | Fiber design |
| Product destination | XUDA |
| Optic fiber material | PMMA |
| Sheath material | PE |
| Detection system | Thru beam |
| Optic fiber use | General use |
| Optic fiber length | 10 m |
| External diameter | 2.2 mm |
| Minimum bending radius | 25 mm |
| Optic fiber core | 1 x Ø 1 mm |
| Net weight | 0.02 kg |
| Ambient air temperature for operation | -25…60 °C |
| Ambient air temperature for storage | -40…80 °C |
| Vibration resistance | +/- 1.5 mm (f= 10…55 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
