Description
Screw optocoupler OBIC0100-5-12VDC: 5-12VDC Rated control supply voltage/ solid-state output rated 4.5-58VDC, 1 mA up to 100 mA with integrated LED. New original ABB part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Function | Boxed optocoupler R600 |
|---|---|
| Rated Control Supply Voltage (Us) | 5 … 12 V DC |
| Output | Solid-State |
| Output Signal | 4.5 … 58VDC / 1 mA … 100 mA |
| Terminal Type | Screw Terminals |
| Standards | CAN/CSA C22.2 No.14 | IEC/EN 63000 | IEC/EN 60947-5-1 | UL 508 |
| Product Net Width | 6 mm |
| Product Net Height | 67.5 mm |
| Product Net Depth / Length | 70 mm |
| Product Net Weight | 0.02 kg |
| EAN | 4013614508035 |
| Customs Tariff Number | 85369095 |
| Object Classification Code | K |
| Country of origin | MA |
| Manufacturer standard delivery time | 5 days |
| Packaging unit | Box x 10 |
| Product status (supplier data) | Active |
Independent distributor — not an authorised ABB dealer. All technical parameters are taken verbatim from the official ABB product data for this exact order code; packaging, customs and delivery data come from the supplier list entry for the same code.
