Description
Allen-Bradley 800T-00HX2KB6 — 30mm Selector Switch. Manufacturer designation: 30mm Selector Switch 800T PB. 30.5mm Type 4/13 Sel. Switch-Illum., 2 Pos., No Color, Std. Knob Maint., KB6 Maintained Cam, No Contacts, No Contacts New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Allen-Bradley |
|---|---|
| Article No. (MPN) | 800T-00HX2KB6 |
| Product Category | Switches & Socket-Outlets |
| Country of Origin | United States of America |
| Type | 30mm Selector Switch |
| Illumination lamp type | Incandescent |
| Illumination module type | Operator only |
| Suitable for illumination | True |
| Enclosure compatibility (NEMA type) | 1, 4, 12, 13 |
| Hole diameter | 30.5 mm |
| Illumination module termination tightening torque | 6 – 8 in-lb / 0.7 – 0.9 N-m |
| Operator function | Maintained |
| Operator mechanical design life (cycles, min.) | 200000 |
| Operator type | Selector switch |
| Shock | 25 G (contact fragility)/100 G (no damage) |
| Type of electric connection | Screw connection |
| Vibration | 10 G maximum (except logic reed) |
| Operator cam code | KB6 |
| Operator cap color | None |
| Operator cap type | Standard knob |
| Operator construction/material | Metal |
| Terminations with finger safe covers | False |
| Hazardous location rating | False |
| Humidity | 50 % |
| EAN / GTIN | 611320240009 |
| Condition | New & original |
| Availability | On request |
Independent distributor — not an authorised Allen-Bradley dealer. All parameters are taken from the official manufacturer documentation.
