Description
Telemecanique Sensors XCKJ105 — Limit switch. Manufacturer designation: Limit switch, XC Standard, XCKJ, rotary head. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | XCKJ105 |
| Product Category | Sensors |
| Range of product | Telemecanique Limit switches XC Standard |
| Series name | Standard format |
| Product or component | Limit switch |
| Device short name | XCKJ |
| Body type | Fixed |
| Head type | Rotary head |
| Body material | Zamak |
| Head material | Zamak |
| Fixing mode | By the body |
| Movement of operating | Rotary |
| Type of operator | Spring return without operating lever |
| Type of approach | Lateral approach, 1 or 2 programmable direction |
| Cable entry | 1 entry tapped for Pg 13.5 cable gland, cable outer |
| Contacts type and | 1 NC + 1 NO |
| Contact operation | Snap action |
| Contacts insulation form | Zb |
| Positive opening | With |
| Positive opening minimum torque | 0.5 N.m |
| Minimum torque for tripping | 0.25 N.m |
| [Ithe] conventional enclosed thermal current | 10 A |
| [Ui] rated insulation voltage | 300 V conforming to UL 508 |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
