Description
Telemecanique Sensors XUSL2E30H151N — Safety light curtain type 2. Manufacturer designation: Safety light curtain type 2, Telemecanique. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | XUSL2E30H151N |
| Product Category | Safety Switching Devices |
| Range of product | Telemecanique Safety light curtains XUSL |
| Product or component | Safety light curtain type 2 |
| Device short name | XUSL2E |
| Output type | 2 safety outputs OSSD solid-state PNP (arc |
| Product specific | For hand protection |
| [R] Resolution | 30 mm |
| [Sn] nominal sensing | 0…12 M by cabling |
| [Hp] Height protected | 1510 mm |
| Number of beams | 76 |
| Type of start / restart | Automatic |
| External Device | Selected by wiring |
| Detection system | Transmitter-receiver system |
| Response time | 19.5 ms |
| Kit composition | Adjustable mounting bracket(s) |
| [EAA] effective aperture angle | 5 ° at 3 m |
| [Us] rated supply voltage | 24 V DC +/- 20 % |
| [Ie] rated operational current | 2 A |
| Current consumption | 42 mA no-load transmitter |
| Output current limits | 0.4 A for safety outputs OSSD |
| Output voltage | 24 V |
| Output circuit type | DC |
| Condition | New & original |
| Availability | On request |
Download official Telemecanique Sensors datasheet (PDF)
Independent distributor — not an authorised Telemecanique Sensors dealer. All parameters are taken from the official manufacturer documentation.
