Description
Telemecanique Sensors ZCD25 — Limit switch body. Manufacturer designation: Limit switch body, Limit switches XC Standard,. New original part, traceable to the manufacturer. Availability and price on request.
Technical Specifications
| Manufacturer | Telemecanique Sensors |
|---|---|
| Article No. (MPN) | ZCD25 |
| Product Category | Sensors |
| Range of product | Telemecanique Limit switches XC Standard |
| Series name | Standard compact |
| Product or component | Limit switch body |
| Device short name | ZCD |
| Body type | Fixed |
| Associated head | ZCEH2 |
| Body material | Zamak |
| Contacts type and | 1 NC + 1 NO |
| Contact operation | Slow-break, break before make |
| Associated connection component | ZCDEP20 |
| Contacts insulation form | Zb |
| Contacts material | Silver plated contacts |
| Positive opening | With |
| Minimum actuation speed | 6 m/s |
| [Ui] rated insulation voltage | 300 V conforming to UL 508 |
| 500 v | (pollution degree 3) conforming to IEC 60947-1 |
| 300 v | conforming to CSA C22.2 No 14 |
| [Uimp] rated impulse withstand voltage | 6 KV conforming to IEC 60664 |
| 6 kV | conforming to IEC 60947-1 |
| Short-circuit protection | 10 A cartridge fuse, type gG |
| Condition | New & original |
| Availability | On request |
